內藏式中空(氣)油壓二爪夾盤-2-JAW HOLLOW POWER CHUCK FIXTURES (HYDRAULIC)

内藏式中空油壓夾盤適用於工作台面的鉆、銑加工而設計。
With built-in type cylinder, it is ideal for machining application on working table.

• 1. 氣缸防銹處理:
     在潮濕及工作環境較差的情況，氣缸內部經防銹處理，不會生銹或卡死。
     Rust-proof for Pneumatic Cylinder:
     Inside wall of cylinder being rustproof treated; cylinder can work under wet or high moisture circumstances without rusty or seized trouble.
  2. 防壓裝置:
     在工作台上的站工作、切屑及冷卻液不易進入夾盤内部Dusts-proof and Waterproof:
     Dust-proof and Waterproof structure prevents work-chips and coolant water from entering into inside of chuck cylinder to maintain its accuracy and lead to longer service life.
  3. 内藏式油缸特性:
     把油缸直接裝置於夾頭內部，更能確保連結的穩定性、提升夾持力，適用於重切削及夾持精度的保持，倍增機械效益。
     Benefit of Built-in Cylinder:
     The cylinder is connected to chuck itself directly for obtaining better stability, less space, and higher machining efficiency.
